Kyocera FS-C8600DN Service Manual

2MN/2N1-1
2-2-3
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Main PWB (MPWB) PARTS PWB MAIN ASSY SP
2 Engine PWB (EPWB) PARTS PWB ENGINE ASSY SP
3 Power source PWB (PSPWB) PARTS UNIT LOW VOLTAGE SP
4 High voltage PWB 1 (HVPWB1) PARTS UNIT HIGH VOLTAGE MAIN SP
5 High voltage PWB 2 (HVPWB2) PARTS UNIT HIGH VOLTAGE TRANSFER SP
6 Operation PWB (OPWB) PARTS PWB PANEL ASSY SP
7 Front PWB (FRPWB) PARTS PWB FRONT CLR ASSY SP
8 Feed PWB 1 (FPWB1) PARTS PWB FEED 1 ASSY SP
9 Feed PWB 2 (FPWB2) PARTS PWB FEED 2 ASSY SP
10 Relay PWB (RPWB) PARTS PWB JUNCTION ASSY SP
11 Motor control PWB (MCPWB) PARTS PWB MOTOR CONTROL ASSY SP
12 LSU relay PWB (LSURPWB) PARTS PWB LSU JUNC CLR ASSY SP
13 APC PWB K (APCPWB-K) -
14 APC PWB M (APCPWB-M) -
15 APC PWB C (APCPWB-C) -
16 APC PWB Y (APCPWB-Y) -
17 PD PWB K (PDPWB-K) -
18 PD PWB M (PDPWB-M) -
19 PD PWB C (PDPWB-C) -
20 PD PWB Y (PDPWB-Y) -
21 Drum PWB K (DRPWB-K) -
22 Drum PWB M (DRPWB-M) -
23 Drum PWB C (DRPWB-C) -
24 Drum PWB Y (DRPWB-Y) -
25 Transfer PWB (TRPWB) -
26 Fuser PWB (FUPWB) -
27 Fuser IH PWB (FIHPWB) -
28 RFID PWB (RFPWB) PARTS PWB RFID ASSY SP
29 Interface PWB (IFPWB) PARTS PWB KUIO ASSY SP
30 Current PWB (CRPWB) PARTS PWB CURRENT AVE ASSY SP

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
