Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-52
U101 Setting the voltage for the primary transfer
Description
Sets the control voltage for the primary transfer.
Purpose
To change the setting when any density problems, such as too dark or light, occur.
Setting
1. Press the OK key.
2. Select the item to be set.
Setting: [Normal]
1. Select the item to be set.
1. Change the value using the numeric keys.ll
*: 55 ppm model only.
2. Press the OK key. The value is set.
Setting: [Add Color]
1. Select the item to be set.
2. Change the value using the numeric keys.l
3. Press the OK key. The value is set.
Item No. Description
Display Description
Normal Setting the primary transfer positive voltage
Add Color Setting the addition value (The addition value at the surface is
referenced as standard)
Add Color 2nd Setting the addition value for the second side
Surround Correct Environmental correction ON/OFF setting
Display Description
Setting
range
Initial setting
45ppm 55ppm
Full Primary transfer positive volt-
age for yellow (full speed)
0 to 255 126 131
Half Primary transfer positive volt-
age for yellow (half speed)
0 to 255 108 110
3/4 Primary transfer positive volt-
age for yellow at 3/4 times of
line speed
0 to 255 118 118
B/W* Primary transfer positive volt-
age for yellow in black/white
mode
0 to 255 - 135
Display Description
Setting
range
Initial
setting
Normal Regular -127 to 127 2
Heavy4/5 Heavy 4/5 -127 to 127 2

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
