Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-47
4012 Polygon motor C steady-
state error
After polygon motor C is stabi-
lized, the ready signal is at the
H level for 15 s continuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Polygon motor C and LSU relay PWB (YC9)
LSU relay PWB (YC3) and engine PWB
(YC12)
Defective polygon
motor C.
Replace the laser scanner unit (see page 1-
5-17).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
4013 Polygon motor M steady-
state error
After polygon motor M is sta-
bilized, the ready signal is at
the H level for 15 s continu-
ously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Polygon motor M and LSU relay PWB (YC7)
LSU relay PWB (YC3) and engine PWB
(YC12)
Defective polygon
motor M.
Replace the laser scanner unit (see page 1-
5-17).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
4014 Polygon motor Y steady-
state error
After polygon motor Y is stabi-
lized, the ready signal is at the
H level for 15 s continuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Polygon motor Y and LSU relay PWB
(YC11)
LSU relay PWB (YC3) and engine PWB
(YC12)
Defective polygon
motor Y.
Replace the laser scanner unit (see page 1-
5-17).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
4101 BD initialization error K
After polygon motor K is
driven, the BD signal is not
detected for 1 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Laser scanner unit and LSU relay PWB
(YC5)
LSU relay PWB (YC3) and engine PWB
(YC12)
Defective PD PWB
K.
Replace the laser scanner unit (see page 1-
5-17).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
