Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-80
8330 CF blade motor error
(4000-sheet finisher)
When initial operation, CF
blade sensor does not turn on
within 3 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
CF blade motor and CF main PWB (YC15)
CF blade sensor and CF main PWB (YC20)
Defective CF blade
sensor.
Replace the CF blade sensor.
Defective CF blade
motor.
Replace the CF blade motor.
Defective CF main
PWB.
Replace the CF main PWB and check for
correct operation.
8340 CF staple motor error 1
(4000-sheet finisher)
Staple JAM (center-folding
unit) has been detected twice
in a row. (The home position
could not be detected in 600
ms since the motor was driven
after jam was detected twice.)
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
CF staple unit and CF main PWB (YC13)
Defective CF sta-
ple sensor.
Replace the CF staple unit.
Defective CF sta-
ple motor.
Defective CF main
PWB.
Replace the CF main PWB and check for
correct operation.
8350 CF side registration motor 1
error
(4000-sheet finisher)
When initial operation, CF
side registration sensor 1
does not turn on within 1 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
CF side registration motor 1 and CF main
PWB (YC10)
CF side registration sensor 1 and CF main
PWB (YC20)
Defective CF side
registration sensor
1.
Replace CF side registration sensor 1.
Defective CF side
registration motor
1.
Replace CF side registration motor 1.
Defective CF main
PWB.
Replace the CF main PWB and check for
correct operation.
8360 CF main motor error
(4000-sheet finisher)
During driving the motor, lock
signal is detected for 1 s con-
tinuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
CF main motor and CF main PWB (YC16)
Defective CF main
motor.
Replace the CF main motor.
Defective CF main
PWB.
Replace the CF main PWB and check for
correct operation.
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
