Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-84
8930 Center-folding unit backup
error
(4000-sheet finisher)
Read and write data does not
match 3 times in succession.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
CF main PWB (YC7) and DF main PWB
(YC9)
Improper installa-
tion EEPROM.
Check the installation of the EEPROM and
remedy if necessary.
Defective CF main
PWB.
Replace the CF main PWB and check for
correct operation.
F000 Communication error
between main PWB and
operation PWB
Defective main
PWB.
Turn the main power switch off/on to restart
the machine. If the error is not resolved,
replace main PWB (see page 1-5-44).
Defective opera-
tion PWB.
Replace the operation PWB and check for
correct operation.
F010 Main PWB checksum error Defective main
PWB.
Turn the main power switch off/on to restart
the machine. If the error is not resolved,
replace main PWB (see page 1-5-44).
F040 Communication error
between main PWB and
print engine
Defective main
PWB.
Turn the main power switch off/on to restart
the machine. If the error is not resolved,
replace main PWB (see page 1-5-44).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
F050 Print engine ROM check-
sum error
Defective engine
software.
Install the engine software.
Defective engine
PWB.
Turn the main power switch off/on to restart
the machine. If the error is not resolved,
replace engine PWB (see page 1-5-49).
F278 Power supply in drive sys-
tem error
The main power
switch was turned
off before the
machine was shut-
down, or a power
failure has
occurred.
Turn on power.
(To switch off power, after confirming the
data lamp is turned off, perform shut-down
on the operation panel, turn power off.)
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
