Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-48
U089 Outputting a MIP-PG pattern
Description
Selects and outputs the MIP-PG pattern created in the machine.
Purpose
To check machine status when adjusting image printing, using MIP-PG pattern output.
Method
1. Press the OK key.
2. Select the MIP-PG pattern to be output and press the OK key.
3. Press the menu key.
4. Press the OK key. A MIP-PG pattern is output.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description Purpose
256Gradation 256-gradation PG To check the gradation reproducibility
Color Belt Four color belts PG To check the developer state and the
engine section ID
Gray(C) Cyan PG To check the drum quality
Gray(M) Magenta PG To check the drum quality
Gray(Y) Yellow PG To check the drum quality
Gray(K) Black PG To check the drum quality
White Blank paper PG To check the drum quality
Gradation Gray 5-graduation gray PG To check for vertical lines on the laser
scanner unit
Sample Set Four color belts PG,
Cyan PG, Magenta PG,
Yellow PG and Black PG
Pattern output for LLU assurance
application

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
