Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-25
7000 DF staple operation error DF staple sensor (DFSTS) is not turned on within
specified time after driving the DF staple motor
(DFSTM) (4000-sheet finisher).
H
7001 DF staple sensor (DFSTS) is not turned on within
specified time after driving the DF staple motor
(DFSTM) (1000-sheet finisher).
H
7100 CF paper entry sensor
non arrival jam
CF paper entry sensor (CFPES) is not turned on even
if a specified time has elapsed after the machine eject
signal was received.
H
7110 CF paper entry sensor
stay jam
CF paper entry sensor (CFPES) is not turned off within
specified time of its turning on.
H
7200 CF eject sensor non
arrival jam
CF eject sensor (CFES) is not turned on within speci-
fied time since centerfold operation starts.
H
7210 CF eject sensor stay jam During centerfold operation, CF eject sensor (CFES) is
not turned off within specified time of its turning on.
H
7300 CF eject sensor non
arrival jam
CF eject sensor (CFES) is not turned on within speci-
fied time since three fold operation starts.
H
7310 CF eject sensor stay jam During three fold operation, CF eject sensor (CFES) is
not turned off within specified time of its turning on.
H
7400 CF side registration sen-
sor 2 non arrival jam
CF side registration sensor 2 (CFSRS2) is not turned
on within specified time after driving the CF side regis-
tration motor 2 (CFSRM2).
H
7500 CF side registration sen-
sor 1 non arrival jam
CF side registration sensor 1 (CFSRS1) is not turned
on within specified time after driving the CF side regis-
tration motor 1 (CFSRM1).
H
7600 CF staple operation error CF staple sensor (CFSTS) is not turned on within
specified time after driving the CF staple motor
(CFSTM).
H
7700 CF paper conveying sen-
sor non arrival jam
CF paper conveying sensor (CFPCS) is not turned on
even if a specified time has elapsed after the machine
eject signal was received.
H
7710 CF paper conveying sen-
sor stay jam
CF paper conveying sensor (CFPCS) is not turned off
within specified time of its turning on.
H
7800 MB eject sensor non
arrival jam
MB eject sensor (MBES) is not turned on even if a
specified time has elapsed after the machine eject sig-
nal was received.
I
7810 MB eject sensor stay jam MB eject sensor (MBES) is not turned off within speci-
fied time of its turning on.
I
7950 Paper interval error jam An illegal inter-page or inter-print interval has occurred
(4000-sheet finisher).
H
7951 An illegal inter-page or inter-print interval has occurred
(1000-sheet finisher).
H
Code Contents Conditions
Jam
loc
ation*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
