Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-121
U464 Setting: [Print Rate(B/W)]
1. Change the setting value using the numeric keys.
2. Press the OK key. The value is set.
Method: [Calib]
1. Select [Execute].
2. Press the OK key. Calibration is executed.
* : Duplicates selecting [System Menu] - [Adjustment/Maintenance] - [Calibration].
The same operation as System menu.
Setting: [Edge Reduction]
1. Select On or Off.
Initial setting: On
Press the OK key. The setting is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U465 Data reference for ID correction
Description
References the data related to ID correction.
Purpose
To check the corresponding data.
Method
1. Press the OK key.
2. Select the item to be reference.
3. Press the OK key
Item No. Description
Display Description
Setting
range
Initial
setting
Threshold Proportion of black/white printing 0 to 100 (%) 50
Display Description
On Enable smoothing edges
Off Disable smoothing edges
Display Description
TCONT Developer bias control value after ID correction
Laser Power Scaling factor to the value determined in light amount calibration
Bias Calib Sensor value for toner thick layer calibration
T7 CTD T7 control value
Stress Durability
