Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-122
U465 Displaying: [TCOUNT]
Select [TCOUNT]. The current value is displayed.
Displaying: [Laser Power]
1. Select [Laser Power]. The current value is displayed.
Displaying: [Bias Calib]
1. Select [Bias Calib]. The current value is displayed.
Displaying: [T7 CTD]
1. Select [T7 CTD]. The current value is displayed.
Item No. Description
Display Description
Before(C) Developer bias control value for cyan before ID correction
Before(M) Developer bias control value for magenta before ID correction
Before(Y) Developer bias control value for yellow before ID correction
Before(K) Developer bias control value for black before ID correction
After(C) Developer bias control value for cyan after ID correction
After(M) Developer bias control value for magenta after ID correction
After(Y) Developer bias control value for yellow after ID correction
After(K) Developer bias control value for black after ID correction
Display Description
C Scaling factor to the value determined in light amount calibration (cyan)
M Scaling factor to the value determined in light amount calibration (magenta)
Y Scaling factor to the value determined in light amount calibration (yellow)
K Scaling factor to the value determined in light amount calibration (black)
Display Description
C Sensor value for toner thick layer calibration (cyan)
M Sensor value for toner thick layer calibration (magenta)
Y Sensor value for toner thick layer calibration (yellow)
K Sensor value for toner thick layer calibration (black)
Display Description
C T7 control value (cyan)
M T7 control value (magenta)
Y T7 control value (yellow)
K T7 control value (black)
