Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-86
(1) No image appears (entirely white).
(2) No image appears (entirely black).
Print example Causes Check procedures/corrective measures
Defective
transfer
bias output.
Defective connector cable
or poor contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
High voltage PWB 2 (YC1) and engine PWB
(YC8)
Defective high voltage PWB
2.
Replace the high voltage PWB 2
(see page 1-5-55).
Defective engine PWB. Replace the engine PWB (see page 1-5-49).
Defective
developer
bias output.
Defective connector cable
or poor contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
High voltage PWB 1 (YC1, 2) and engine
PWB (YC16)
High voltage PWB 1 (YC3, 4) and engine
PWB (YC17)
Defective high voltage PWB
1.
Replace the high voltage PWB 1
(see page 1-5-54).
Defective engine PWB. Replace the engine PWB (see page 1-5-49).
No LSU
laser is out-
put.
Defective laser scanner
unit.
Replace the laser scanner unit
(see page 1-5-17).
Defective engine PWB. Replace the engine PWB (see page 1-5-49).
Print example Causes Check procedures/corrective measures
No main
charging.
Defective connector cable
or poor contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
High voltage PWB 1 (YC1, 2) and engine
PWB (YC16)
High voltage PWB 1 (YC3, 4) and engine
PWB (YC17)
Defective charger roller unit. Replace the charger roller unit
(see page 1-5-31).
Defective high voltage PWB
1.
Replace the high voltage PWB 1
(see page 1-5-54).
Defective engine PWB. Replace the engine PWB (see page 1-5-49).
The laser is
activated
simultane-
ously for all
colors.
Defective laser scanner
unit.
Replace the laser scanner unit
(see page 1-5-17).

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
