Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-16
U000 Service status page (1)
Figure 1-3-2
Item No. Description
Firmware version 2MN_2000.001.001 2011.10.27
27/10/2011 12:00
[XXXXXXXX] [XXXXXXXX] [XXXXXXXX]
Service Status Page
Printer
Memory status
Total Size
Controller Information
[XXXXXXXXXX]
2.0 GB
Option Slot 1.0 GB
Standard Size 1.0 GB
Time
Local Time Zone
Date and Time
Time Server
+01:00 Amsterdam
27/10/2010 12:00
10.183.53.13
Installed Options
Paper feeder
Side Feeder
Finisher
IC Card Authentication Kit (B)
Security Kit (E)
Data Security Kit (E)
UG-34
UG-33
USB Keyboard
USB Keyboard Type
Cassette (500 x 2)
Cassette (3000)
1000-Finisher
Installed
Installed
Installed
Installed
Connected
US-English
Print Coverage
Average(%)
K: 1.10
C: 2.20
M: 3.30
Y: 4.40
Last Page K/C/M/Y(%)
/ Usage Page(A4/Letter Conversion)
/ 1111111.11
/ 2222222.22
/ 3333333.33
/ 4444444.44
1.00 / 2.22 / 3.33 / 4.44
FRPO Status
Default Pattern Switch
Default Font Number
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
e-MPS error control
RP Code
1234 5678 9012
5678 9012 3456
9012 3456 7890
3456 7890 1234
B8
C5*1000+C2*100+C3
Y6
0
00000
0
1
.
.
.
.
.
.
.
.
(1)
(9)
(8)
(7)
(12)
(10)
(11)
(22)
(23)
(24)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(25)
(26)
(27)
(28)
(29)
(6)
(2)
(3) (4) (5)

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
