Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-93
U241 Checking the operation of the switches of the finisher
Description
Displays the status of each switches and sensors of 1000-sheet finisher or 4000-sheet finisher.
Purpose
To check the operation of each switches and sensors of the 1000-sheet finisher or 4000-sheet
finisher.
Method
1. Press the OK key.
2. Select the item to be checked.
3. Press the OK key
Method: [Finisher]
1. Turn each switch or sensor on and off manually to check the status.
When a switch/sensor is detected to be in the ON position, the display for that switch/sensor
will be “1”.
Item No. Description
Display Description
Finisher Checking the switch and sensor of the document finisher
Mail Box Checking the switch and sensor of the mailbox
Booklet Checking the switch and sensor of the center-folding unit
Top Mail Box Checking the motor of the top mailbox
Punch Checking the switch and sensor of the punch unit
Display Description
Switch 1 0000000
1 First digit: DF front cover switch (DFFCSW)
1 Second digit: DF eject cover switch (DFECSW)
*1
1 Third digit: DF top cover switch (DFTCSW)
*2
1 Fourth digit: DF tray sensor 1 (DFTS1)
1 Fifth: DF tray sensor 2 (DFTS2)
*1
1 Sixth: DF tray sensor 3 (DFTS3)
1 Seventh: DF tray sensor 4 (DFTS4)
Switch 2 0000000
1 First digit: DF tray sensor 5 (DFTS5)
*1
1 Second digit: DF tray upper surface sensor (DFTUSS)
1 Third digit: DF paper entry sensor (DFPES)
1 Fourth digit: DF sub eject sensor (DFSES)
*1
1 Fifth: DF middle eject sensor (DFMES)
1 Sixth: DF drum sensor (DFDRS)
*1
1 Seventh: DF slide sensor (DFSLS)
