Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-92
U240
Method: [Solenoid]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Method: [Mail Box/Top Mail Box]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Method: [Booklet]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
EjectUnlock(Fix) DF eject release motor (DFERM) fixed drive position
EjectUnlock(Full) DF eject release motor (DFERM) full-open drive position
Punch Punch motor (PUM) is turned on
Punch Move Punch slide motor (PUSLM) is turned on
Display Description
Sub Tray DF feedshift solenoid (DFFSSOL) is turned on
Save Drum DF drum solenoid (DFDRSOL) is turned on
Booklet DF center fold solenoid (DFCFSOL) is turned on
Punch Punch solenoid (PUSOL) is turned on
Three Fold CF feedshift solenoid (CFFSSOL) is turned on
Display Description
Conv MB drive motor (MBDM) is turned on at paper conveying
Branch MB drive motor (MBDM) is turned on at feedshift operation
Display Description
Folding CF main motor (CFMM) is turned on
Blade CF blade motor (CFBM) is turned on
Bundle Up CF adjustment motor 2 (CFADM2) is turned on
Bundle Down CF adjustment motor 1 (CFADM1) is turned on
Staple CF staple motor (CFSTM) is turned on
Width Test(A3) CF side registration motor 1, 2 (CFSRM1, 2) is turned on
Width Test(LD) CF side registration motor 1, 2 (CFSRM1, 2) is turned on
Feed In CF paper entry motor (CFPEM) is turned on

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
