Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-113
U332 Setting the size conversion factor
Description
Rate: Sets the coefficient of nonstandard sizes in relation to the A4/Letter size. The coefficient
set here is used to convert the black ratio in relation to the A4/Letter size and to print the service
status page.
Mode: Make settings on the color print coverage counter displays, as well as the coverage
threshold.
Method
1. Press the OK key.
2. Select the item to set.
Setting: [Rate]
Purpose: To set the coefficient for converting the black ratio for nonstandard sizes in relation to
the A4/Letter size.
1. Change the setting using the numeric keys.
2. Press the OK key. The value is set.
Setting: [Mode]
Purpose: Make settings on the color print color/coverage counter displays.
1. Select the mode.
Initial setting: 0
* : If ‘0’ has been changed to ‘1’, revert the U260 feed/eject counter switch to its initial state
(Eject).
2. Press the OK key. The setting is set.
Setting: [Level 1/2]
Purpose:Make settings on the color print coverage threshold.
1. Select the item.
2. Change the setting using the numeric keys.
3. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Rate Size coefficient
Mode Toggling full-color count and color coverage count display
Level 1 Low coverage threshold value
Level 2 Middle coverage threshold value
Display Description Setting range Initial setting
Rate Size coefficient 0.1 to 3.0 1.0
Display Description
0 Full-color count display
1 Color coverage count display
Display Description Setting range Initial setting
Level 1 Low coverage threshold value 0.1 to 99.8 1.0
Level 2 Middle coverage threshold value 0.1 to 99.9 2.5

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
