Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-15
4301 Duplex sensor 1 non
arrival jam
Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 1.
G
4302 Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 2.
G
4303 Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 3 (paper feeder/large capacity
feeder).
G
4304 Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 4 (paper feeder/large capacity
feeder).
G
4305 Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 5 (side multi tray/side deck).
G
4306 Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 6 (side paper feeder/side large
capacity feeder).
G
4307 Duplex sensor 1 (DUS1) does not turn on during paper
feed from cassette 7 (side paper feeder/side large
capacity feeder).
G
4309 Duplex sensor 1 (DUS1) does not turn on during paper
feed from MP tray.
G
4311 Duplex sensor 1 stay jam Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 1.
F
4312 Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 2.
F
4313 Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 3 (paper feeder/large capacity
feeder).
F
4314 Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 4 (paper feeder/large capacity
feeder).
F
4315 Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 5 (side multi tray/side deck).
F
4316 Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 6 (side paper feeder/side large
capacity feeder).
F
4317 Duplex sensor 1 (DUS1) does not turn off during paper
feed from cassette 7 (side paper feeder/side large
capacity feeder).
F
4319 Duplex sensor 1 (DUS1) does not turn off during paper
feed from MP tray.
F
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
