Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-29
U031 Checking switches and sensors for paper conveying
Description
Displays the on-off status of each paper detection switch or sensor on the paper path.
Purpose
To check if the switches and sensors for paper conveying operate correctly.
Method
1. Press the OK key.
2. Turn each switch or sensor on and off manually to check the status.
When a switch/sensor is detected to be in the ON position, the display for that switch/sensor
will be “1”.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Switch 1 0000000
1 First digit: MP feed sensor (MPFS)
1 Second digit: Feed sensor 1 (FS1)
1 Third digit: Feed sensor 2 (FS2)
1 Fourth digit: Paper conveying sensor (PCS)
1 Fifth: Registration sensor (RS)
1 Sixth: Loop sensor (LPS)
1 Seventh: Switchback sensor (SBS)
Switch 2 0000000
1 First digit: Duplex sensor 1 (DUS1)
1 Second digit: Duplex sensor 2 (DUS2)
1 Third digit: BR conveying sensor 1 (BRCS1)
1 Fourth digit: BR conveying sensor 2 (BRCS2)
1 Fifth: BR eject sensor (BRES)
1 Sixth: Eject full sensor (EFS)
1 Seventh: Fuser eject sensor (FUES)
Switch 3 0000000
1 First digit: Middle sensor (MS)
1 Second digit: JS eject sensor (JSES)
1 Fourth digit: Third digit: Regist deflection sensor (RDS)
1 Fifth: Tray full sensor(JSTFS)
1 Sixth: Eject sensor (ES)
