Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-28
U030 Checking the operation of the motors
Description
Drives each motor.
Purpose
To check the operation of each motor.
Method
1. Press the OK key.
2. Select the motor to be operated.
3. Press the OK key. The operation starts.
4. To stop operation, press the Back key.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Feed Paper feed motor (PFM) is turned on
DLP(K) Developer motor K (DEVM-K) is turned on
DLP(CMY) Developer motor MCY (DEVM-MCY) is turned on
Fuser Fuser motor (FUM) is turned on
SB(CW) Eject motor (EM) is turned on clockwise
SB(CCW) Eject motor (EM) is turned on counterclockwise
CMY Release Color release motor (CRM) is turned on
JobSepa JS eject motor (JSEM) is turned on
Regist Registration motor (RM) is turned on
Bridge1 BR conveying motor 1 (BRCM1) is turned on
Bridge2 BR conveying motor 2 (BRCM2) is turned on
Belt Meand Transfer motor (TRM) is turned on
Press Release Transfer release motor (TRRM) is turned on
Fuser Release Fuser release motor (FURM) is turned on
DU1 Duplex motor 1 (DUM1) is turned on
DU2 Duplex motor 2 (DUM2) is turned on
Mid Roller Middle motor (RM) is turned on
InnerJobSepa(CW) JS conveying motor (JSCM) is turned on clockwise
InnerJobSepa(CCW) JS conveying motor (JSCM) is turned on counterclock-
wise

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
