Kyocera FS-C8600DN - Remarks on Engine PWB Replacement

2MN/2N1
1-6-4
1-6-3 Remarks on engine PWB replacement
When replacing the engine PWB, remove the EEPROM (U100) from the engine PWB that has been removed
and then reattach it to the new engine PWB.
Figure 1-6-4
U100
EEPROM
Engine PWB
