2MN/2N1
1-5-71
(4) Detaching and refitting the lift motor 1 and 2
Procedure
1. Remove the rear lower cover (see page
1-5-56).
2. Remove the power source assembly
(see page 1-5-51).
3. Remove the connector each.
4. Remove two screws each.
5. Remove the lift motor 1 and 2.
6. Check or replace the lift motor and refit
all the removed parts.
Figure 1-5-112
Screws
Connector
Lift motor
Lift motor 1
Lift motor 2
To Next Page
