Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-71
U135 Checking toner motor operation
Description
Drives toner motors.
Purpose
To check the operation of toner motors.
Remarks
When driving the toner motors long time or several times, developer section becomes the toner
full and is locked.
Method
1. Press the OK key.
2. Select [Toner].
3. Press the OK key. The operation starts.
4. To stop the operation, press the Back key.
Completion
Press the Back key after operation stops. The screen for selecting a maintenance item No. is dis-
played.
U136 Setting toner near end detection
Description
Sets the level that indicates the number of sheets that can be printed from occurrence of toner
near end to toner empty.
Purpose
To change the setting to advance detection of near end if the interval from toner near end to toner
empty seems too short.
Setting
1. Press the OK key.
2. Select the item to be set.
3. Change the value using the numeric keys.
Increasing the setting makes the interval from toner near end to toner empty longer.
Decreasing the setting makes the interval from toner near end to toner empty shorter.
If 0 is set, toner near end will not be detected.
4. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Toner Toner motor (TM) is turned on
Display Description
Setting
range
Initial
setting
CMY Setting the level of cyan/magenta/yellow toner 0 to 9 3
K Setting the level of black toner 0 to 9 3

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
