Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-1-2
Warm-up
time
(22 °C/71.6
°F, 60% RH)
Power on 41 s or less
45 s or less
Low Power 25 s or less
25 s or less
Sleep
41 s or less
45 s or less
Paper
capacity
Cassette
550 sheets (64 g/m
2
)
500 sheets (80 g/m
2
)
MP tray
A4/Letter or less
165 sheets (64 g/m
2
) 150 sheets (80 g/m
2
)
More than A4/Letter
55 sheets (64 g/m
2
) 50 sheets (80 g/m
2
)
Output tray
capacity
Main tray 500 sheets (80 g/m
2
)
Job separa-
tor tray
250 sheets (80 g/m
2
)
(When the Documents Finisher is installed, 100 sheets.)
Photoconductor a-Si (drum diameter 30 mm)
Image write system Semiconductor laser
Charging system Charger roller
Developing system
Touch down developing system
Developer: 2-component
Toner replenishing: Automatic from the toner container
Transfer system
Primary: Roller transfer system (Intermediate transfer belt)
Secondary:Roller transfer system
Separation system Small diameter separation, Separation electrode
Cleaning system
Drum: Counter blade, Cleaning roller
Transfer belt: Fur brush
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system
Belt fusing
Heat source: IH
Abnormally high temperature protection devices: thermostat
CPU PowerPC 750GL/750 MHz
Main
memory
Standard 1024 MB (1024 MB DIMMx 1)
Maximum 2048 MB(1024 MB DIMMx 2)
Hard Disk 160 GB (160 GB x 1) (standard)
Interface
Standard
USB Interface Connector: 1 (Hi-Speed USB)
USB Port: 2 (Hi-Speed USB)
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
Option
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
Resolution 600 × 600 dpi
Operating system
Windows XP, Windows Server 2003, Windows Vista, Windows 7, Windows
Server 2008, Apple Macintosh OS 10.x
Page description language PRESCRIBE
Item
Specifications
45 ppm 55 ppm

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
