2MN/2N1
1-5-37
4. Remove the cleaning pre brush by turn-
ing it as shown.
5. Check or replace the cleaning pre brush
and refit all the removed parts.
Figure 1-5-56
*: Hook the springs back in place onto the
cleaning pre brush when installing.
Figure 1-5-57
Cleaning pre brush
1
2
2
Spring
Spring
