Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-53
YC14
10 24V2 O 24 V DC 24 V DC power to RYPWB
Connected to
relay PWB
11 DU_FAN - - Not used
12 DU_CL_LOWER_
REM
O 0/24 V DC DUCL2: On/Off
13 DU_OPEN_SW I 0/3.3 V DC DUCSW: On/Off
14 DU2_B/ O 0/24 V DC (pulse) DUM2 drive control signal
15 DU2_A/ O 0/24 V DC (pulse) DUM2 drive control signal
16 DU2_B O 0/24 V DC (pulse) DUM2 drive control signal
17 DU2_A O 0/24 V DC (pulse) DUM2 drive control signal
18 GND - - Not used
YC15
1 24V1 O 24 V DC 24 V DC power to PCUSW
Connected to
paper con-
veying unit
switch
2 N.C - - Not used
3 24V2 I 24 V DC 24 V DC power from PCUSW
YC16
1 24V2 O 24 V DC 24 V DC power to HVPWB2
Connected to
high voltage
PWB 2
2 GND - - Ground
YC17
1 GND - - Ground
Connected to
relay PWB
2 GND - - Ground
3
CLN_SOL_REM
- - Not used
4
24V2
- - Not used
5 MPF_LIFT_MOT_
B
O 0/24 V DC MPLM: On/Off
6 MPF_LIFT_MOT_
A
O 0/24 V DC MPLM: On/Off
7 24V2 O 24 V DC 24 V DC power to RYPWB
8 MPF_CL_REM O 0/24 V DC MPPFCL: On/Off
9 MPF_JAM_SENS I 0/3.3 V DC MPFS: On/Off
10 MPF_LIFT_DOW
N_SENS
I 0/3.3 V DC MPLS2: On/Off
11 MPF_LIFT_UP_S
ENS
I 0/3.3 V DC MPLS1: On/Off
12 MPF_PPR_SET I 0/3.3 V DC MPPS: On/Off
13 LED_3.3V3 O 3.3 V DC 3.3 V DC power to RYPWB
14 MPF_LNG I 0/3.3 V DC MPPLSW: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
