Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-57
Connector Pin Signal I/O Voltage Description
YC1
1 GND - - Ground
Connected to
engine PWB
2 FEED_MOT_REM I 0/3.3 V DC PFM: On/Off
3 FEED_MOT_CLK I 0/3.3 V DC (pulse) PFM clock signal
4 FEED_MOT_RDY O 0/3.3 V DC PFM ready signal
5 FEED_MOT_DIR I 0/3.3 V DC PFM drive switch signal
6 FEED_CL1_REM I 0/24 V DC PFCL1: On/Off
7 FEED_CL2_REM I 0/24 V DC PFCL2: On/Off
8 ASIST_CL2 I 0/24 V DC ASCL2: On/Off
9 LIFT_MOT2_REM I 0/24 V DC LM2: On/Off
10 GND - - Ground
11 LIFT_MOT1_REM
1
I 0/24 V DC LM1: On/Off
12 CAS2_WID O 0/3.3 V DC PWSW2: On/Off
13 CAS2_LNG3 O 0/3.3 V DC PLSW2: On/Off
14 CAS2_LNG2 O 0/3.3 V DC PLSW2: On/Off
15 CAS2_LNG1 O 0/3.3 V DC PLSW2: On/Off
16 CAS1_WID O 0/3.3 V DC PWSW1: On/Off
17 CAS1_LNG3 O 0/3.3 V DC PLSW1: On/Off
18 CAS1_LNG2 O 0/3.3 V DC PLSW1: On/Off
19 CAS1_LNG1 O 0/3.3 V DC PLSW1: On/Off
20 GND - - Ground
21 CAS2_QUANT2 O 0/3.3 V DC PGS2(L): On/Off
22 CAS2_QUANT1 O 0/3.3 V DC PGS2(U): On/Off
23 CAS1_QUANT2 O 0/3.3 V DC PGS1(L): On/Off
24 CAS1_QUANT1 O 0/3.3 V DC PGS1(U): On/Off
25 LIFT_MOT1_LOC
K
O 0/3.3 V DC LM1 lock signal
26 LIFT_MOT2_LOC
K
O 0/3.3 V DC LM2 lock signal
27 CURRENT_SIG O 0/3.3 V DC Current signal
28 V-FEED_CL I 0/24 V DC PCCL: On/Off
29 COVER_OPEN O 0/3.3 V DC PCCSW: On/Off
30 FEED2_SENS O 0/3.3 V DC PFPCS1: On/Off
31 CAS1_P0 O 0/3.3 V DC FS1: On/Off
32 CAS1_LIFT_UP O 0/3.3 V DC LS1: On/Off
33 GND - - Ground
34 CAS1_EMPTY O 0/3.3 V DC PS1: On/Off

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
