Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-59
YC3
12 GND - - Ground
Connected to
paper length
switch 1/2,
paper width
switch 1/2, lift
motor 1/2,
paper gauge
sensor 1(U)/
(L) and paper
gauge sen-
sor 2(U)/(L)
13 LIFT_MOT1_RET O 0/24 V DC LM1: On/Off
14 LIFT_MOT1_DR O 0/24 V DC LM1: On/Off
15 LIFT_MOT2_RET O 0/24 V DC LM2: On/Off
16 LIFT_MOT2_DR O 0/24 V DC LM2: On/Off
17 LED_5V O 5 V DC 5 V DC power to PGS1(U)
18 GND - - Ground
19 CAS1_QUANT1 I 0/3.3 V DC PGS1(U): On/Off
20 LED_5V O 5 V DC 5 V DC power to PGS1(L)
21 GND - - Ground
22 CAS1_QUANT2 I 0/3.3 V DC PGS1(L): On/Off
23 LED_5V O 5 V DC 5 V DC power to PGS2(U)
24 GND - - Ground
25 CAS2_QUANT1 I 0/3.3 V DC PGS2(U): On/Off
26 LED_5V O 5 V DC 5 V DC power to PGS2(L)
27 GND - - Ground
28 CAS2_QUANT2 I 0/3.3 V DC PGS2(L): On/Off
YC4
1 FEED_CL1_REM O 0/24 V DC PFCL1: On/Off
Connected to
paper feed
clutch 1/2
2 24V2 O 24 V DC PFCL124 V DC power to PFCL1
3 FEED_CL2_REM O 0/24 V DC PFCL2: On/Off
4 24V2 O 24 V DC 24 V DC power to PFCL2
YC5
1 NC - - Not used
Connected to
paper con-
veying clutch
2 24V2 O 24 V DC 24 V DC power to PCCL
3 V-FEED_CL O 0/24 V DC PCCL: On/Off
YC6
1 LED_5V O 5 V DC 5 V DC power to PCS
Connected to
paper con-
veying sen-
sor and
paper con-
veying cover
switch
2 GND - - Ground
3 FEED2_SENS I 0/3.3 V DC PCS: On/Off
4 FEED_COVER_O
PEN
I 0/3.3 V DC PCCSW: On/Off
5 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
