2MN/2N1
1-2-45
5. Fit the duct unit to the machine using
the removed screw A, M3 x 8 tap-tight P
screw (black) and two M3 x 8 tap-tight S
screws (black).
Figure 1-2-65
M3 x 8 tap-tight
S screws (black)
M3 x 8 tap-tight
P screw (black)
Screw A
