Model 831 Manual Recovery After Improper Shutdown 7-19
•If the user responds by selecting not to store the data, the
sequence moves to Step 2.
Step 2 The user is prompted to reset the instrument
• If the user responds by selecting to reset the instrument,
the instrument is reset.
• If there is no user response to the prompt within ten
seconds, the instrument is reset.
When the user is present, he/she
must eventually select to store the
data, reset the instrument, or take no
action, in which case the instrument
will be automatically reset.
• If the user responds by selecting not to reset the
instrument, the sequence moves back to Step 1.
This sequence is diagrammed below
FIGURE 7-16 Improper Shutdown Sequence, Case 2
Instrument Reset
No Response for 10 seconds
No
Reset Instrument prompt
Ye s
No
Save Data prompt
Data Saved
Ye s
To Next Page
