Model 831 Manual Summary of Displays and Icons 3-7
Summary of Displays and Icons
Tabs
Data is presented in tabbed format. Move between tabs by
using the right and left Softkeys.
Page
Tabs are divided into pages that logically group the data
together (i.e., 1/3 Octave data on the Live tab). Tabs may
contain only one page or multiple pages. Navigate up or
down to different pages by using the 8 (UP) or 2
(DOWN) keys. The position of the scroll bar indicates the
sequence of pages on tabs.
Scroll Bar and Section Indicator
The scroll bar represents the complete tab. The section
indicator shows the location of the page you are viewing.
Power Indicator
The following icons indicate the power source driving the
Model 831 and the supply available to operate it.
Battery Power
The battery icon indicates the state of the battery charge by
the width of the interior shaded portion. The two icons in
FIGURE 3-6 indicate a fully charged battery and a nearly
discharged battery.
FIGURE 3-6 External Power
The RESET key is used to reset a measurement. For detailed information on
using the Reset key, see "Resetting the Measurement" on page 7-13.
The TOOLS key is used to set a number of parameters not associated with a
specific measurement, such as setting date and time, managing power options
and setting personal preferences (i.e. language, decimal and date formats, etc.).
Table 3-1 Keypad Hardkeys
