15-26 Storing Data Model 831 Manual
Storing Data
Press the 7 key to store data.
FIGURE 15-34 File Save Dialog
Viewing Stored Data
The stored data displays are the
same regardless of the method used
for the measurement.
Following a measurement, the stored data can be viewed on
the RT-60 tab pages as follows:
• RT-60 Spectra
• RT-60 Decay Curve
• Excitation Levels
• Quality Summary (two pages for 1/3 octave data)
• Quality Detail
• Accuracy Grade
Note: The Data Explorer only shows
files from the current instrument
mode.
Use the Data Explorer utility to view stored measurements
on the 831. Data Explorer is opened by pressing the
3
key
and then selecting the icon labeled "Data Explorer". When
this utility opens, it will display the saved files. To open one
of the files, highlight the file and press
5. The data can
now be viewed just as was outlined in the "Viewing and
Analyzing Results" section. One exception is that the data
