19-10 Location Measurement Using 831-INT Model 831 Manual
Average Weather
Average weather data appears on the Overall tab shown in
FIGURE 19-12.
.
FIGURE 19-12 Overall Weather Display
Location Measurement Using 831-INT
The optional firmware 831-GPS
must be enabled in order to utilize a
GPS with the Model 831. Note that
daylight savings time is not
supported.
To provide global positioning information to the Model 831,
Larson Davis offers the GPS001 USB GPS Receiver with a
magnetic mount. This device is connected directly to the
USB port of the Model 831,
Setup
The GPS Mode field will only appear
when the USB Host Port is set to On.
The setup parameters for the GPS are entered using the
Preferences tab of System Properties, shown in FIGURE
19-13.
