16-2 Sound Recording Setup Model 831 Manual
Sound Recording Setup
The Sound Recording feature of the Model 831 implements
the digital recording of the sound signal output from the
measurement microphone. Regardless of the sound
recording type(s) to be utilized, the basic recording
parameters are set as described in this section.
Note that the default values for these
parameters are as shown in
FIGURE 16-1.
Sound Recording is setup using the Sound tab of the
Measurement Setup View, as shown in Figure 16-1.
FIGURE 16-1 Sound Recording Setup Menu
Sample Rate
The Sound Recorder feature of the Model 831 is a powerful
tool for source identification and for advanced analysis. The
sample rates used for source identification are 8k, and 16k
sps (samples per second) and the sample rates used for
advanced analysis are 24k and 48k sps.
