4-16 Setup Manager Model 831 Manual
At this point the parameter changes made from the Settings
Screen have not yet been implemented in the instrument.
Select either Ye s or No, and press
5 to implement the
changes or cancel the changes, respectively. This will return
the Data Display Screen to the display.
Setup Manager
Due to the need to assign names to
user-defined setups, it is much easier
to create and save these using G4 or
G3 software.
The Setup Manager permits the user to create and store a
number of user-defined measurement setups for easy recall
and use.
To activate the Setup Managers, press the
3 (TOOLS) key.
to open the Control Panel. Highlight the Setup Manager
icon, as shown in FIGURE 4-14
FIGURE 4-14 Control Panel
