13-22 Link to Time History and Measurement History Model 831 Manual
FIGURE 13-22 Role of Left/Right Arrow Keys: By-Time Event Spectral Time History
Link to Time History and Measurement History
When Time History and/or Measurement History have also
been enabled, a link is provided to make a rapid transition
from any of the Event History displays to the same point in
time of the Time History and/or Measurement History
display.
Left and Right Arrow keys
Change Frequency
Left and Right Arrow keys
Change Record
Left and Right Arrow keys
Change Event
Switch role of left/right
arrow keys from
“Change Frequency” to
“Change Record”
Switch role of left/right arrow keys
from “Change Record” to “Change
Event”
Switch role of left/right
arrow keys from “Change
Event” to “Change
Frequency”
