A-60 Frequency Response Model 831 Manual
Output Connector
Switchcraft TA5M
5-Pin male
Compatibility
Use with ½" electret microphone having about 50 mV/Pa sensitivity and meeting the mechanical
requirements of IEC 61094-4 or ¼" electret microphone using the Larson Davis ADP043 adapter.
In the interest of constant product improvement, specifications are subject to change without notice.
Larson Davis provides a complete line of acoustic measurement tools including dosimeters, sound
level meters, real time analyzers, preamps, calibrators and microphones.
Pin Signal
1 Signal Ground
2 Signal Output
3 Power Supply + 35 Volts
4 Preamp sense
5 No Connection
Shell Connect to preamp housing
Table A-25 Output Connector
