Loading...
•
Or
, use the up/down buttons
to increase or decrease the time value in
increments of 200 ps. Or, touch one of the preset value button
s:
The preset
Time
values are as follows:
Max.
20.0 s
Default
50.0 ns
Min.
2 ns
The preset
Events
values are as follows:
Max.
1,000,000,000
events
Default
1 event
Min.
1 event
6. Choose
Positive
or
Negative
slope
82
SDA-OM-E Rev
H
81
83
