Chapter 8: MegaRAID Storage Manager Window and Menus

MegaRAID Storage Manager Main Menu

Figure 132 Parity Size

8.5.8.2 Mirror Data Size

Mirror Data Size is used to determine the size used for storing redundant information on RAID 1 and RAID 10 virtual

drives.

Follow these steps to view the Mirror Data Size.

1. In the Logical view, click on the Virtual Drive node.

The Mirror data size is displayed for RAID 1 and RAID 10 volumes, as shown in the following figure.

Figure 133 Mirror Data Size

NOTE The parity size and mirror data size are not displayed for RAID 0 and

RAID 00 volumes.
