Chapter 8: MegaRAID Storage Manager Window and Menus
GUI Elements in the MegaRAID Storage Manager Window and Menus
8.6 GUI Elements in the MegaRAID Storage Manager Window and Menus
This section describes the graphical user interface (GUI) elements used in the MegaRAID Storage Manager software.
8.6.1 Device Icons
The following icons in the left panel represent the controllers, drives, and other devices.
Status
System
Controller
Backplane
Enclosure
Port
Drive group
Virtual drive
Online drive
Power save mode
Dedicated hotspare
Global hotspare
Battery backup unit (BBU)
Tape drive
CD-ROM
Foreign drive
Unconfigured drive
Locked SED
Unlocked SED
