LSI Corporation
- 57 -
12Gb/s MegaRAID SAS Software User Guide
March 2014
Chapter 4: Ctrl-R Utility
Creating a Storage Configuration
4.6.5 Activating an Unlimited Key
When you activate an unlimited key, the following dialog appears.
Figure 29 Activating an Unlimited Key
4.7 Creating a Storage Configuration
You can use the Ctrl-R Utility to configure RAID drive groups and virtual drives to create storage configurations on
systems with LSI SAS controllers.
1. In the VD Mgmt screen, navigate to the controller and press the F2 key.
2. Press Enter.
The Create New VD screen appears.
NOTE You can use the Create New VD dialog to create virtual drives for
Unconfigured Good drives. To create virtual drives for existing drive
groups, navigate to a drive group and press the F2 key to view the Add
VD in Drive Group dialog. The fields in the Add VD in Drive Group
dialog are the same as in the Create New VD dialog.
