12Gb/s MegaRAID SAS Software User Guide

March 2014

Chapter 12: Using MegaRAID Advanced Software

Using the MegaRAID CacheCade Advanced Software

Figure 217 Create CacheCade™ - Summary Dialog

8. Click Next.

The summary dialog appears, as shown in the following figure. This dialog displays the drive group name, the

number of drives, the total capacity, the free capacity, the CacheCade virtual drive name, and the capacity being

used.
