Chapter 4: Ctrl-R Utility
Creating a Storage Configuration
Figure 32 Create CacheCade Virtual Drive
3. Enter a name for the CacheCade virtual drive in the Name field.
4. Select a SSD from the Select SSD box. The size of the SSD is reflected in the Size field (in the Basic Settings box).
5. Press OK.
A message appears, stating that the CacheCade virtual drive has been created.
To view the virtual drives associated with this CacheCade virtual drive, click Associated VDs in the Create
CacheCade Virtual Drive dialog.
The Associated Virtual Drives dialog appears.
