Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1019
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00876
C00877
Parameter | Name:
C00876 | MCI input words
Data type: UNSIGNED_16
Index: 23699
d
= 5C93
h
Display of the 16 bit input values of the communication module
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00876/1 LP_MciIn
: wCtrl
C00876/2 LP_MciIn
: wIn2
C00876/3 LP_MciIn
: wIn3
C00876/4 LP_MciIn
: wIn4
C00876/5 LP_MciIn
: wIn5
C00876/6 LP_MciIn
: wIn6
C00876/7 LP_MciIn
: wIn7
C00876/8 LP_MciIn
: wIn8
C00876/9 LP_MciIn
: wIn9
C00876/10 LP_MciIn
: wIn10
C00876/11 LP_MciIn
: wIn11
C00876/12 LP_MciIn
: wIn12
C00876/13 LP_MciIn
: wIn13
C00876/14 LP_MciIn
: wIn14
C00876/15 LP_MciIn
: wIn15
C00876/16 LP_MciIn
: wIn16
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00877 | MCI output words
Data type: UNSIGNED_16
Index: 23698
d
= 5C92
h
Display of the 16 bit output values of the communication module
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00877/1 LP_MciOut
: wState
C00877/2 LP_MciOut
: wOut2
C00877/3 LP_MciOut
: wOut3
C00877/4 LP_MciOut
: wOut4
C00877/5 LP_MciOut
: wOut5
C00877/6 LP_MciOut
: wOut6
