15 Parameter reference
15.2 Parameter list
1020
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00890
C00877/7 LP_MciOut
: wOut7
C00877/8 LP_MciOut
: wOut8
C00877/9 LP_MciOut
: wOut9
C00877/10 LP_MciOut
: wOut10
C00877/11 LP_MciOut
: wOut11
C00877/12 LP_MciOut
: wOut12
C00877/13 LP_MciOut
: wOut13
C00877/14 LP_MciOut
: wOut14
C00877/15 LP_MciOut
: wOut15
C00877/16 LP_MciOut
: wOut16
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00877 | MCI output words
Data type: UNSIGNED_16
Index: 23698
d
= 5C92
h
Parameter | Name:
C00890 | MCI_InOut: Inversion
Data type: UNSIGNED_16
Index: 23685
d
= 5C85
h
From version 02.00.00
This parameter serves to invert the control/status bits of the MCI port blocks.
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Active Bit set = inversion active
... ...
Bit 15 Active
Subcodes Lenze setting Info
C00890/1 0x0000 LP_MciIn
: Invert.Ctrl_B0..15
C00890/2 0x0000 LP_MciOut: Invert.State_B0..15
C00890/3 0x0000 LP_MciIn
: Invert. In2_B0..15
C00890/4 0x0000 LP_MciOut: Invert.Out2_B0..15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
