Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1021
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00905
C00909
C00910
Parameter | Name:
C00905 | Motor phase direction of rotation
Data type: UNSIGNED_8
Index: 23670
d
= 5C76
h
From version 04.00.00
To correct such misconnected motor phases, the rotating field of the inverter's output can be reversed by selecting
"1: Inverted". In this case, a phase will be reversed at the output of the inverter.
Note:
Up to and including version 07.00.00, this function may only be activated for the following motor control types:
• V/f characteristic control (VFCplus)
• Energy-saving V/f characteristic control (VFCplusEco)
For all other motor control types, this function must not be activated because the set control mode would not work
in that case!
From version 12.00.00, this function may be activated for all motor control types with the exception of the ones for
synchronous motor.
The activation of this function does not affect the control types for synchronous motor since these control types
require an in-phase connection of the synchronous motor.
Selection list (Lenze setting printed in bold)
0 not inverted
1inverted
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00909 | Speed limitation
Data type: INTEGER_16
Index: 23666
d
= 5C72
h
Max. positive/negative speed for all motor control modes
Setting range (min. value | unit | max. value)
0.00 % 175.00
Subcodes Lenze setting Info
C00909/1 120.00 % Max. pos. speed
C00909/2 120.00 % Max. neg. speed
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00910 | Frequency limitation
Data type: UNSIGNED_16
Index: 23665
d
= 5C71
h
Max. positive/negative output frequency for all motor control modes
• For dependencies see chapters "Override
" and "Profile entry".
Setting range (min. value | unit | max. value)
0 Hz 1300
Subcodes Lenze setting Info
C00910/1 1000 Hz Max. pos. output frequency
C00910/2 1000 Hz Max. neg. output frequency
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
