Lenze 8400 - Page 1022

15 Parameter reference
15.2 Parameter list
1022
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00915
C00916
C00917
C00918
Parameter | Name:
C00915 | Motor cable length
Data type: UNSIGNED_16
Index: 23660
d
= 5C6C
h
Single motor cable length for calculating the motor cable resistance
• The calculated motor cable resistance is displayed in C00917
.
Setting range (min. value | unit | max. value) Lenze setting
0.0 m 1000.0 5.0 m
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00916 | Motor cable cross-section
Data type: UNSIGNED_16
Index: 23659
d
= 5C6B
h
Motor cable cross-section of a phase/cable for calculating the motor cable resistance
• The calculated motor cable resistance is displayed in C00917
.
Setting range (min. value | unit | max. value) Lenze setting
0.50 mm^2 100.00 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00917 | Motor cable resistance
Data type: UNSIGNED_16
Index: 23658
d
= 5C6A
h
Display of the motor cable resistance of a motor cable phase
• The motor cable resistance is calculated from the motor cable length set in C00915
and the motor cable cross-
section set in C00916
.
Display range (min. value | unit | max. value)
0 mOhm 64000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00918 | SC: Start motor magnetising current
Data type: UNSIGNED_8
Index: 23657
d
= 5C69
h
From version 10.00.00
If the servo control (SC
) mode is selected and the inverter is enabled, the speed setpoint for motor control will only
be enabled when the motor magnetising current has reached the threshold value set here.
• The adjustable percentage threshold value refers to the rated magnetising current (C00095
).
Setting range (min. value | unit | max. value) Lenze setting
0%9087 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
