Lenze 8400 - Page 1062

15 Parameter reference
15.2 Parameter list
1062
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01124
C01130
Parameter | Name:
C01124 | Sync correction width
Data type: UNSIGNED_8
Index: 23451
d
= 5B9B
h
From version 04.00.00
Correction increment for device synchronisation
• If the cycle times of the synchronisation signal differs and phase-locken loop (PLL) differ from each other, this
setting defines the measure the phase-locking loop is reset with.
• If synchronisation is not reached, select a higher correction constant.
• The optimum setting depends on quartz precision and must be determined empirically if required.
Synchronisation of the internal time base
Selection list (Lenze setting printed in bold)
1 100ns
2 200ns
3 300ns
4 400ns
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01130 | LS_RetainData: Selection
Data type: UNSIGNED_16
Index: 23445
d
= 5B95
h
From version 11.00.00
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 wIn1
Bit 1 wIn2
Bit 2 wIn3
Bit 3 wIn4
Bit 4 dnIn1
Bit 5 dnIn2
Bit 6 dnIn3
Bit 7 dnIn4
Bit 8 bIn1
Bit 9 bIn2
Bit 10 bIn3
Bit 11 bIn4
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C01130/1 0x000F LS_RetainData
: Selection bSetRetain_1
C01130/2 0x00F0 LS_RetainData
: Selection bSetRetain_2
C01130/3 0x0F00 LS_RetainData
: Selection bSetRetain_3
C01130/4 0x0FFF LS_RetainData
: Selection bLoadParams
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
