15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01248
Bit 10 Max. speed limit 1 ≡ Due to the set machine parameters, the maximum
speed for specifications in [units/s] are limited to the
factor 150 %.
Bit 11 Quick stop is active 1 ≡ Quick stop function is active.
Bit 12 Quick stop standstill is active 1 ≡ Standstill during active quick stop function (no ramp
generation).
Bit 13 Max. speed is pending 1 ≡ The speed setpoint has exceeded the limit of
± 199.99 %.
Possible cause:
• Too high influence due to speed override
• Increased speed by reduced acceleration with little
jerk
Bit 14 Position resolution limit 1 ≡ The position resolution calculated by machine data
entries has been limited to the maximum display area of
214748.3647 [Incr./Unit] with reference to the display in
C01205/0
. The real value is higher!
Bit 15 Modulo buffer overflow
Bit 16 Ck10: position > cycle length
Bit 17 Ck10: invalid speed
Bit 18 Ck10: invalid acceleration
Bit 19 Ck10: invalid deceleration
Bit 20 Ck10: invalid final speed
Bit 21 Ck10: reversal at overchange
Bit 22 Ck10: distance calculation error
Bit 23 Reserved
Bit 24 Reserved
Bit 25 Reserved
Bit 26 Reserved
Bit 27 Reserved
Bit 28 Reserved
Bit 29 Reserved
Bit 30 Reserved
Bit 31 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01247 | MCK: Diagnostic word
Data type: UNSIGNED_32
Index: 23328
d
= 5B20
h
Parameter | Name:
C01248 | MCK: Ref. step
Data type: UNSIGNED_8
Index: 23327
d
= 5B1F
h
From version 16.00.00
Selection list Info
0 No Operation Initial step when changing to the homing mode
1 RefMarke: Search Search travel until reference pre-stop mark
2 RefMarke: Stop Stop when reference pre-stop mark has been detected
3 RefMarke: Reversal Reversal of reference pre-stop mark
4 HW-Limit: Search Search travel until limit switch
5 HW-Limit: Stop Stop when limit switch has been detected
6 HW-Limit: Reversal Reversal of limit switch
7 M-Limit: Search Search travel until torque limit has been detected
