Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1067
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01202
C01203
C01204
C01205
Parameter | Name:
C01202 | MCK: iM motor/process
Data type: UNSIGNED_16
Index: 23373
d
= 5B4D
h
Gearbox factor - motor
• Entry of the gearbox factor as numerator/denominator ratio (numerator = motor speed and denominator =
output speed of gearbox) or from the number of teeth of the gearbox arrangement.
Machine parameter
Setting range (min. value | unit | max. value)
1 65535
Subcodes Lenze setting Info
C01202/1 1 MCK: iM: Numerator gearbox factor Z2
C01202/2 1 MCK: iM: Denominator gearbox factor Z1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01203 | MCK: iG motor/position encoder
Data type: UNSIGNED_16
Index: 23372
d
= 5B4C
h
Gearbox factor - position encoder
• Entry of the gearbox factor as numerator/denominator ratio, with numerator = motor speed and denominator
= position encoder speed.
Machine parameter
Setting range (min. value | unit | max. value)
1 65535
Subcodes Lenze setting Info
C01203/1 1 MCK: iG: Numerator (motor speed)
C01203/2 1 MCK: iG: Denominator (encoder speed)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01204 | MCK: Feed constant
Data type: INTEGER_32
Index: 23371
d
= 5B4B
h
The feed constant corresponds to the movement of the machine during one revolution of the gearbox output shaft.
• The value is entered in application units referred to one revolution.
Machine parameter
Setting range (min. value | unit | max. value) Lenze setting
0.0001 units/rev. 214748.3647 360.0000 units/rev.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01205 | MCK: Position resolution
Data type: INTEGER_32
Index: 23370
d
= 5B4A
h
Display of the number of increments corresponding to one unit.
• 1 motor revolution ≡ 65536 increments
Machine parameter
Display range (min. value | unit | max. value)
0.0000 Incr./unit 214748.3647
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
