15 Parameter reference
15.2 Parameter list
1066
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01150
C01151
C01201
C01141/1 0.000 s L_Transient_5
: Pulse duration
C01141/2 0.000 s L_Transient_6
: Pulse duration
C01141/3 0.000 s L_Transient_7
: Pulse duration
C01141/4 0.000 s L_Transient_8
: Pulse duration
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01141 | L_Transient 5-8 pulse duration
Data type: UNSIGNED_16
Index: 23434
d
= 5B8A
h
Parameter | Name:
C01150 | L_PhaseIntK: Function
Data type: UNSIGNED_8
Index: 23425
d
= 5B81
h
Loading behaviour of the integrator
Selection list Info
0 Loading with level Load integrator with TRUE level at the input bLoad
1 Loading with edge Load integrator with FALSE/TRUE edge at the input
bLoad
2 Loading with level + reset Load integrator when the comparison value (C01151
) is
reached or with TRUE level at the bLoad input
Subcodes Lenze setting Info
C01150/1 0: Loading with level L_PhaseIntK_1
: Function
C01150/2 0: Loading with level L_PhaseIntK_2
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01151 | L_PhaseIntK: Compare
Data type: INTEGER_32
Index: 23424
d
= 5B80
h
Comparison value
Setting range (min. value | unit | max. value)
0 2147418112
Subcodes Lenze setting Info
C01151/1 0 L_PhaseIntK_1
: Comparison value
C01151/2 0 L_PhaseIntK_2: Comparison value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01201 | MCK: Cycle
Data type: INTEGER_32
Index: 23374
d
= 5B4E
h
From version 06.00.00
Cycle for Modulo measuring system
• When the cycle is set to 0 units (Lenze setting), the traversing range is unlimited (classical measuring system).
Activation of the Modulo measuring system
Setting range (min. value | unit | max. value)
0.0000 units 214748.3647
Subcodes Lenze setting Info
C01201/1 0.0000 units MCK: Cycle
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
