Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1065
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01139
C01140
C01141
Subcodes Lenze setting Info
C01138/1 0: High edge L_Transient_1
: Function
C01138/2 0: High edge L_Transient_2
: Function
C01138/3 0: High edge L_Transient_3
: Function
C01138/4 0: High edge L_Transient_4
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01138 | L_Transient 1-4: Function
Data type: UNSIGNED_8
Index: 23437
d
= 5B8D
h
Parameter | Name:
C01139 | L_Transient 1-4: Pulse duration
Data type: UNSIGNED_16
Index: 23436
d
= 5B8C
h
From version 04.00.00
Setting range (min. value | unit | max. value)
0.000 s 60.000
Subcodes Lenze setting Info
C01139/1 0.000 s L_Transient_1
: Pulse duration
C01139/2 0.000 s L_Transient_2
: Pulse duration
C01139/3 0.000 s L_Transient_3
: Pulse duration
C01139/4 0.000 s L_Transient_4
: Pulse duration
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01140 | L_Transient 5-8: Function
Data type: UNSIGNED_8
Index: 23435
d
= 5B8B
h
Selection of edge evaluation
Selection list
0High edge
1Low edge
2High and low edge
Subcodes Lenze setting Info
C01140/1 0: High edge L_Transient_5
: Function
C01140/2 0: High edge L_Transient_6
: Function
C01140/3 0: High edge L_Transient_7
: Function
C01140/4 0: High edge L_Transient_8
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01141 | L_Transient 5-8 pulse duration
Data type: UNSIGNED_16
Index: 23434
d
= 5B8A
h
Setting range (min. value | unit | max. value)
0.000 s 60.000
Subcodes Lenze setting Info
