Lenze 8400 - Page 1117

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1117
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02252
C02256
C02260
Parameter | Name:
C02252 | LS_WriteParamList: Kp position controller
Data type: UNSIGNED_16
Index: 22323
d
= 5733
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 1/s 500.00
Subcodes Lenze setting Info
C02252/1 5.00 1/s LS_WriteParamList
: c254_val1
C02252/2 5.00 1/s LS_WriteParamList
: c254_val2
C02252/3 5.00 1/s LS_WriteParamList
: c254_val3
C02252/4 5.00 1/s LS_WriteParamList
: c254_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02256 | LS_WriteParamList: Moment of inertia
Data type: UNSIGNED_32
Index: 22319
d
= 572F
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 kg cm^2 6000000.00
Subcodes Lenze setting Info
C02256/1 0.00 kg cm^2 LS_WriteParamList
: c273_val1
C02256/2 0.00 kg cm^2 LS_WriteParamList
: c273_val2
C02256/3 0.00 kg cm^2 LS_WriteParamList
: c273_val3
C02256/4 0.00 kg cm^2 LS_WriteParamList
: c273_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02260 | LS_WriteParamList: Speed sensor selection
Data type: UNSIGNED_8
Index: 22315
d
= 572B
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Selection list
0 No sensor
1 Sensor signal FreqIn12
2 Encoder signal FreqIn67
5 Encoder signal FreqIn1267
Subcodes Lenze setting Info
C02260/1 0: No sensor LS_WriteParamList
: c495_val1
C02260/2 0: No sensor LS_WriteParamList
: c495_val2
C02260/3 0: No sensor LS_WriteParamList
: c495_val3
C02260/4 0: No sensor LS_WriteParamList
: c495_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
